Plate ‘n’ Sheet

"Plate N Sheet paid for itself first time"
Mary S, Cameron Park, CA

Plate ‘n’ Sheet will create and unfold a 2D template and 3D model in under a minute

Unfolding software for commonly used shapes used in the Metals, Plastics and Insulation Industries. Stand-alone program. Does not require additional software. Print the pattern layout or export as a DXF file to CNC machine or other CAD software.

See our new video about Plate ‘n’ Sheet

(Loads local ASVIC page)


AViCAD CAD Software

When we say Plate ‘n’ Sheet does everything for you – we mean it really does everything for you. Plate ā€™nā€™ Sheet requires little training and zero CAD experience.

  • Standalone – No CAD required
  • Creates hundreds of variations
  • Fast, accurate and simple to use
  • Perfect for CNC Plotters and Plasma devices
  • Saves as DXF
  • Has a Built-In Area and Mass Calculation
  • Rotates 3D models in real time
  • Supports Lap Join
  • Export your drawing directly to AutoCAD(r) if needed
  • Built-in automatic dimensioning
  • Creates a Material List with Costs Estimator
  • Saves pattern as DXF or export to AutoCAD

Plus many more features…
Visit your local ASVIC office for more.
